Digital weighing sensor load cell single point DNA3 (60-1200kg)
Digital Load Cells can provide an all-in-one, single-point solution all kinds of automatic weighing applications. Since digital sensors are designed with built-in electronics for signal processing, Digital single point load cells are ideal for applications that require compact solutions without the extra bulk of a digital display or an external amplifier board.
Key Features：
1.Equipped with a multi-protocol communication interface, RS485, RS232...
2.Robust, accurate, intelligent and easy to use
3.Calibration-free, various baud rates, good anti-interference
4.Available with software dedicated to the automatic weighing applications
Usage & Applications：
Intelligent garbage recycling cabinet
Intelligent weighing shelves
Smart vending machine
Internet of Things weighing systems
Dimension：
DNA3 Specification：
|
Rated Capacities |
60~1200(kg) |
|
Division |
20000 |
|
Combined Precision |
0.02 %R.O. |
|
30mins Creep |
0.02 %R.O. |
|
Temperature Effect On Output |
0.002 %R.O./℃ |
|
Temperature Effect On Zero |
0.003 %R.O./℃ |
|
Safe Overload |
150 %R.O. |
|
Operating Temperature Range |
-10~40 ℃ |
|
Storage Temperature Range |
-20~60 ℃ |
|
Bridge Impedance |
350±5 Ω |
|
Recommended Excitation |
9 VDC |
|
Operating Excitation Range |
6~12 VDC |
|
Construction |
Aluminum Alloy |
|
Protection Class |
IP65 / IP66 |
|
Cable |
φ5×2m |
|
Recommended Platform Size |
600×600 mm；600×800 mm |
|
Data Rate |
5~40 Times/sec |
|
Communication Method |
RS485/RS232 |
|
Communication Rate |
2400~115200Bps (Default 19200bps) |
|
Mode of Connection |
Red（VCC）,Black（GND）,Green（RS485-A/RX）,White（RS485-B/TX） |
